Graphics Pipeline Hierarchy
There is a hierarchy to the DMX control parameters. In general, object control parameters render individual graphic
images. Global control parameters act upon the composite image created by combining multiple objects. Motion
parameters control the fixture movement and projection.
It is especially important to keep this in mind when applying graphical effects. At the lowest level, Graphic effects are
applied to an individual 3-D Graphic Object. Any Global effects applied affect each object in the combined Object image.
Finally, motion effects control the projection of the composite image.
Below is a representation of the Graphics Engine Hierarchy, it is only showing 4 layers for clarity.
