High End Systems MMS100 - Effect Matte

Effect Matte
Mattes
Effect Mode parameter DMX value = 144
The Global Effect lets you select from a variety of provided patterns to superimpose over the composite image. Modifier
parameters select the pattern and effects for a matte.
Modifier 1 Value
Dmx Value =
0
Black transparent, use matte color
Dmx Value =
1
Black transparent, inverting matte color
Dmx Value =
2
White transparent, use matte color
Dmx Value =
3
White transparent, then invert matte color
Dmx Value =
4
Black transparent using a Graphic Object media file content as the matte texture
Dmx Value =
5
White transparent using a Graphic Object media file content as the matte texture
Dmx Value =
6
Black transparent with grayscale used as alpha
Dmx Value =
7
White transparent with grayscale used as alpha
Dmx Value =
8
Black transparent with grayscale not used as alpha
Dmx Value =
9
White transparent with grayscale not used as alpha
Dmx Value =
10
Black transparent, with matte color controlled by Modifier 3 as lookup in internal color gradient
map
Dmx Value =
11
Black transparent, with matte color controlled by Modifier 3 as lookup in internal color gradient
map and inverted
Modifier 2 Value
The first 20 DMX values are assigned to the following Matte pattern options:
Modifier 3 Value
Modifier 1 DMX Values 0 - 3
NA
Not Used
Modifier 1 DMX Values = 4 - 9
0
Graphic Object 1 texture without applied Effects
1
Graphic Object 1 texture including its first applied Effect
2
Graphic Object 1 texture including its first two applied Effects
3
Graphic Object 1 texture including its first three applied Effects
10
Graphic Object 2 texture without applied Effects
11
Graphic Object 2 texture including its first applied Effect
12
Graphic Object 2 texture including its first two applied Effects
13
Graphic Object 2 texture including its first three applied Effects
20
Graphic Object 3 texture without applied Effects
21
Graphic Object 3 texture including its first applied Effect
22
Graphic Object 3 texture including its first two applied Effects
23
Graphic Object 3 texture including its first three applied Effects
Modifier 1 DMX Values =10 - 11
0-255
Color selected as a look up value from an internal gradient.
