MSpeed (Motor Speed Translation)
The MSpeed parameter allows the motion system to calculate positional data with a finer resolution than what a DMX data
stream can provide. MSpeed movement is extremely smooth because the fixture controls movements in a way that is
independent of DMX refresh rates. Extremely slow movements are better obtained by the use of Mspeed instead of using
a console cross-fade values.
In Addition, the Use of Mspeed allows all targeted motors to reach their targeted positions at the same time even though
they have they may have a different distance to move.
MSpeed times vary from 0.15 seconds to 252.7 seconds.
The table below lists the MSpeed (motor) movement times and their corresponding DMX controller values.
• If you have a numeric-type DMX controller, use the Value Decimal (dec.) column.
• If you have a fader-type DMX controller, use the Value Percentage (%) column.
• If your DMX controller allows you to program hex values, use the Value (hex) column.
Time (sec.)
Value (dec.)
Value (%)
Value (hex)
0.15 255 100 FF
0.15
254
100
FE
0.17
253
99
FD
0.19
252
99
FC
0.21
251
98
FB
0.25 250 98 FA
0.29
249
98
F9
0.35
248
97
F8
0.41
247
97
F7
0.47
246
96
F6
0.55
245
96
F5
0.63
244
96
F4
0.73
243
95
F3
0.83
242
95
F2
0.94
241
95
F1
1.05 240 94 F0
1.18
239
94
EF
1.31
238
93
EE
1.45
237
93
ED
1.60
236
93
EC
1.75 235 92 EB
1.92
234
92
EA
2.09
233
91
E9
2.27
232
91
E8
2.46
231
91
E7
2.66
230
90
E6
2.86
229
90
E5
3.07
228
89
E4
3.29
227
89
E3
3.52
226
89
E2
3.76
225
88
E1
4.00
224
88
E0
4.25
223
87
DF
