MMS100 Mirror Head Homing
When the MMS100 fixture is connected to an appropriately-rated power source, it will automatically begin a homing
procedure to verify its orientation. The mirror will move through a number of moves to determine the its precise location
relative to its full range of travel.
There are various ways to home a fixture depending on what is connected to the MMS100
Control Console
Select MMS100 Motion, and select Home Pan/Tilt, found in the Control section of the Slot
Tool-Bar (Hog4 for example)
CMA
Choose the Home Pan / Tilt check box, and press Apply (be sure to deselect once the
procedure begins)
Short Cut - Control
Buttons
Holding down the inner most (i.e. middle) two menu tab buttons for more than two
seconds will home the unit.
Menu Screen - Button
Option
Via Menu Navigation (As Shown)
