High End Systems MMS100 - Menu System Setup - MMS100

Menu System Setup - MMS100
Using the Menu System on the MMS100 will allow all basic configuration setting to be made from one screen. The Control
Screen located on the DMX Tab below is shown below.
All Menu navigation is completed by using the Directional button, the Select Button, and Enter Button located on
the front panel.
• To navigate to a drop-down boxes, use the directional button,
• Pressing the Select Button will open the drop down.
• Use the directional button to highlight an option
• Pressing the Enter button will select the option .
Control Source
Arrow and Select the Source Drop-Down Box. Options are DMX or Art-Net (More Info.)
Control Protocol Version
Arrow and Select the Version Drop-Down Box. Options and V2 or HD (More Info.)
Graphic Layer Number
Arrow and Select the Layer Drop-Down Box. Options are 1-9 Layers (More Info.)
Fixture ID Number
Arrow and Select the Fixture ID Drop-Down Box. Options are 1-255 (More Info.)
Start Channel
Arrow and Select the Start Channel Drop-Down Box. DMX Footprint determines Start Channel options. (More
Info.)
