22
15
Effect 4 Modifier 1
0
0 thru
255
23
16
Effect 4 Modifier 2
0
0 thru
255
24
17
Effect 4 Modifier 3
0
0 thru
255
25
18
Sync To
Indexed.
0
0
No Sync Target, Output is Free-
running
1 thru
255
Fixture ID to use as a Sync target
fixture ID
26
19
Collage Type
Indexed. Note
1
0
0 thru
255
Select Collage type (normal,
segmented, 360 wrap, etc)
27
20
Collage Configuration
Selection
Note 1,2,3
0
0 thru
255
Select Collage Configuration (2x1,
2x2, 3x2, etc)
28
21
Collage Cell Selection
Note 1,2,3
0
0 thru
255
Select Active Collage Cell
29
22
Collage Blending
Adjustment
Indexed. Note
2
0
0 thru
255
Controls Blend Region Adjustment
(Intensity and alternate blend curves)
30
23
Alignment Pattern
Control
Indexed, Note
3
0
0 thru
255
Turns on and off alignment patterns
(both soft and hard edge)
31 + 32
24 + 25
Variable Edge Blend
Horizontal Coarse
16 bit channel
22800
0 thru
65535
Controls horizontal blend region size.
Variable Edge Blend
Horizontal Fine
33 + 34
26 + 27
Variable Edge Blend
Vertical Coarse
16 bit channel
22800
0 thru
65535
Controls vertical blend region size.
34
27
Variable Edge Blend
Vertical Fine
35
28
Mask Select
Indexed. Note
4
0
0
Round mask closing outside in
1 thru
127
Other installed masks, defaults to 0
for unused values.
128
Periodic strobe of round mask closing
in.
129 thru
255
Periodic strobe of other installed
masks, defaults to 128.
36
29
Mask Size
255
0 thru
255
closed to open
37
30
Mask Edge
Indexed. Note
4
0
0 thru
255
hard edge to faded edge. Controls rate
when mask strobe is enabled.
38
31
Keystone Top Left X
0
0 thru
255
Move top left corner x value to center
39
32
Keystone Top Left Y
0
0 thru
255
Move top left corner y value to center
40
33
Keystone Top Right X
0
0 thru
255
Move top right corner x value to
center
41
34
Keystone Top Right Y
0
0 thru
255
Move top right corner y value to
center
42
35
Keystone Bottom Right
X
0
0 thru
255
Move bottom right corner x value to
center
43
36
Keystone Bottom Right
Y
0
0 thru
255
Move bottom right corner y value to
center
44
37
Keystone Bottom Left X
0
0 thru
255
Move bottom left corner x value to
center
45
38
Keystone Bottom Left Y
0
0 thru
255
Move bottom left corner y value to
center
46
39
Keystone X Ratio
0
0 thru
255
X axis linearity
47
40
Keystone Y Ratio
0
0 thru
255
Y axis linearity
48
41
Framing Top Left X
0
0 thru
255
barn door, top left x
49
42
Framing Top Left Y
0
0 thru
255
barn door, top left y
50
43
Framing Top Right X
0
0 thru
255
barn door, top right x
51
44
Framing Top Right Y
0
0 thru
255
barn door, top right y
52
45
Framing Bottom Right X
0
0 thru
255
barn door, bottom right x
