High End Systems MMS100 - Page 264

53
46
Framing Bottom Right Y
0
0 thru
255
barn door, bottom right y
54
47
Framing Bottom Left X
0
0 thru
255
barn door, bottom left x
55
48
Framing Bottom Left Y
0
0 thru
255
barn door, bottom left y
56
49
Framing Fade Top
0
0 thru
255
Applies Gradient to Framing Shutters
57
50
Framing Fade Right
0
0 thru
255
Applies Gradient to Framing Shutters
58
51
Framing Fade Bottom
0
0 thru
255
Applies Gradient to Framing Shutters
59
52
Framing Fade Left
0
0 thru
255
Applies Gradient to Framing Shutters
60
53
Warp Selection
0
0 thru
255
Selects pre-defined warp files
61
54
(Reserved)
62
55
(Reserved)
63
56
Global Control
Indexed.Note
14
0
0 thru
255
64
57
Global Control Modifier
Indexed. Note
15
0
0 thru
255
Graphic Layer Protocol
Graphics Server Layer Control
Start Ch
+
DMX
Channel
Name
Note
Default
Range
Action
65
58
Opacity
0
0 thru 255
Completely Transparent --> Complete
Opaque
66
59
3-D Object File
Indexed
0
0 thru 255
3D object on which image will be rendered
67
60
Media Folder
Indexed
0
0
No selection
1 thru 99
HES Content Library
100 thru
239
User Custom Library
240 thru
254
reserved
255
Input Capture.
68
61
Media File
Indexed
0
0
No selection. Turns off layer output.
1
File 1 --> File 255
69 + 70
62 + 63
In Frame
Coarse
Note 11
0
0 thru
65535
In-Frame number as a percentage of movie
length
In Frame Fine
71 + 72
64 + 65
Out Frame
Coarse
Note 11
0
0 thru
65535
Out-Frame number as a percentage of
movie length.
Out Frame Fine
73
66
Play Mode
Indexed
0
0
play forward looping continuously.default
1
play once, hold on last frame
2
pause
3
play forward once if opacity > 0, hold on
last frame
4
play forward if opacity > 0, looping
continuously
5
pause and rewind to In-Frame
6
scrub In-Frame(note 13)
7
scrub Out-Frame
8
scrub In-Frame with statistics
9
scrub Out-Frame with statistics
10 thru
255
reserved, default to 0
74
67
Play Speed
128
0
normal speed
1 thru 127
slow speeds from slowest to not quite
normal speed
128
normal speed
129 thru
255
fast speeds increasing from just above
normal to fastest
75
68
Sync Mode
Indexed.Note
10
0
0
no selection
