8.4 Command Message Description
148
Message
Terminators
The HiTESTER supports the following message terminators.
The following response message terminators can be selected depending
on the interface setting.
• For details of the method of setting an interface :
See "7.12 Interface Setting (For Communication and Printing)" (p. 133)
Separators
(1) Message unit separator
A semicolon ";" is used as a message unit separator when it is desired to
set out several messages on a single line.
When messages are combined in this way, if a syntax error occurs, all
subsequent messages up to the next terminator will be ignored.
(2) Header separator
In a message which has a header and data, a space " " is used as the
header separator to separate the header from the data.
(3) Data separator
If a message has several data items, commas are required as data sepa-
rators for separating these data items from one another.
•CR
• CR+LF
• CR and LF
:CONFigure:COMParator +1.000E-3,+5.000E-3
