8.7 Command Message Description
191
8
Chapter 8 Controlling the Instrument From a Computer
Sets and queries the measurement network filter
Syntax
Command
Query
Response
:CONFigure:FILTer <characters>
:CONFigure:FILTer?
<characters>
<characters> = ON/ ON1_U2/ ON2_U3/ ON1_U1/ON2_U1/OFF
When network A is selected
OFF : Single-frequency network
ON : Multi-frequency network
When network B1 or B2 is selected(only ST5540)
ON : Network with a frequency characteristic
OFF : Network with 1 k non-inductive resistance only
When network D is selected
ON1_U2 : Network compatible with perception/reaction U2
ON2_U3 : Network compatible with abandonment U3
ON1_U1 : Network compatible with perception/reaction U1
ON2_U1 : Network compatible with abandonment U1
OFF : Body impedance network
When network D is selected
OFF : 1.5 k//0.15 F network
When network E is selected
OFF : 1 k
 network
When network F is selected
OFF : 2 k
 network
When network G is selected
OFF : Network for damp conditions
Function
Command Sets the measurement network filter.
Query Returns the setting of the measurement network filter as alphabetic characters.
Example
Command
:CONFigure:FILTer OFF
Sets the network only with 1 k non-inductive resistance.
(When network B2 is selected)
Query
Response
:CONFigure:FILTer?
:CONFIGURE:FILTER OFF (Headers: ON)
OFF (Headers: OFF)
The network only with 1 k non-inductive resistance has been set.
（When network B2 is selected）
Error
An execution error occurs in the following cases:
• When the measurement mode is not selected
• When a mode other than "leakage current mode" is set
• In automatic measurement (Command)
Note
• Use this command after executing the :MODE command to activate the mea-
surement mode.
Sets and queries the measuring time of automatic measurement
Syntax
Command
Query
Response
:CONFigure:MTIMe <numerical value>
:CONFigure:MTIMe?
<numerical value>
<numerical value> = 1 to 300 (NR1)
Function
Command Sets the measuring time of automatic measurement.
Query Returns the measuring time of automatic measurement as a numeric value.
