8.7 Command Message Description
212
Example
Query
Response
:MEASure:AUTO?
:MEASURE:AUTO +2.345E-03,0,0,0,0,0,0,
+2.362E-03,0,1,0,0,0,0,+2.510E-03,0,0,2,0,0,0,
+2.610E-03,1,1,2,0,0,0,+2.456E-03,0,0,1,0,0,0,
+2.459E-03,0,1,1,0,0,0 (Headers : ON)
+2.345E-03,0,0,0,0,0,0,+2.362E-03,0,1,0,0,0,0,
+2.510E-03,0,0,2,0,0,0,+2.610E-03,1,1,2,0,0,0,
+2.456E-03,0,0,1,0,0,0,+2.459E-03,0,1,1,0,0,0
(Headers: OFF)
The example of response data is shown below:
Error
An execution error occurs in the following cases :
• When the measurement method is set to "manual measurement"
• When the measurement mode is not selected
• Before the start of automatic measurement
• When automatic measurements end in an error
Note
• Use this command after executing the :MODE command to activate the mea-
surement mode.
• Execute this command after confirming the completion of automatic measure-
ment (
:AMC? command). If the command is executed during automatic
measurement, correct measurement results cannot be obtained.
Queries the maximum value after automatic measurement
Maximum
value
Judgement
Power supply
polarity
Equipment under test status
Target
current
2.345 mA PASS Positive phase Normal condition AC + DC
2.362 mA PASS
Negative
phase
Normal condition AC + DC
2.510 mA PASS Positive phase
Single-fault condition
(
Disconnection of protective earth conductor)
AC + DC
2.610 mA FAIL
Negative
phase
Single-fault condition
(
Disconnection of protective earth conductor)
AC + DC
2.456 mA PASS Positive phase
Single-fault condition
(Disconnection of one wire in power line)
AC + DC
2.459 mA PASS
Negative
phase
Single-fault condition
(Disconnection of one wire in power line)
AC + DC
