8.7 Command Message Description
211
8
Chapter 8 Controlling the Instrument From a Computer
Queries the maximum value after automatic measurement
Syntax
Query
Response
:MEASure:AUTO?
<numerical value 1>,<numerical value 2>,<numerical value 3>,<numerical
value 4>,<numerical value 5>,<numerical value 6>,<numerical value 7>
<numerical value 1> = Maximum value(NR3)
<numerical value 2> = Judgement(NR1)
0 : Equal to or less than the allowable value(PASS)
1 : Greater than the allowable value(upper lomit)(FAIL)
2 :Smaller than the allowable value (lower limit)(LOW)
3 :No judgment
<numerical value 3> = Power supply polarity(NR1)
0 : Positive phase
1 : Negative phase
(When the equipment under test is internally powered equipment, touch cur-
rent (enclosure - line). When enclosure - line leakage current, the value is 0)
<numerical value 4> = Equipment under test status(NR1)
0 : Normal condition
1 : Single-fault condition(Disconnection of one wire in power line)
2 : Single-fault condition(
Disconnection of protective earth conductor)
3 : Single-fault condition
(Application of 110% voltage: Positive phase)
4 : Single-fault condition
(Application of 110% voltage: Negative phase)
5 : Single-fault condition (line voltage application : L)
6 : Single-fault condition (line voltage application : N)
<numerical value 5> = Target current (NR1)
0 : AC+DC
1 : AC
2 : DC
3 : ACpeak
<numerical value 6> = Other 110% voltage application
0 : Application of 110% voltage:none
1 : Application of 110% voltage:Positive phase
2 : Application of 110% voltage:Negative phase
(0 for ST5541)
<numerical value 7> =
Specific 110% voltage application
0 : Application of 110% voltage:none
1 : Application of 110% voltage:Positive phase
2 : Application of 110% voltage:Negative phase
(0 for ST5541)
Function
Query Returns all measurement results at once after automatic measurement.
Returns power supply polarity, the maximum value in each combination of
equipment under test status, the corresponding judgment, power supply polar-
ity and equipment under test status as a numeric value.
The data is arranged as follows : <1.Maximum value>, <2.Judgement>,
<3.Power supply polarity>, <4.Equipment under test status>, <5.Target cur-
rent>, <6.Other 110% voltage application>, <7.Specific 110% voltage applica-
tion>, ...
Data 1 through 7 are repeated as many times as the number of automatic mea-
surement combinations.
(unit of (1) maximum value : A)
