8.7 Command Message Description
210
Queries the measurement value
Syntax
Query
Response
:MEASure?
<numerical value 1>,<numerical value 2>
<numerical value 1> = Measurement value (NR3)
<numerical value 2> = Judgement (NR1)
0: Equal to or less than the allowable value (PASS)
1: Greater than the allowable value(upper limit) (FAIL)
2: Smaller than the allowable value (lower limit) (LOW)
3: No judgment
Function
Query Returns the measurement value and judgement result as numeric values.
The data is arranged as follows :
<Measurement value>,<Judgement> (unit : A)
Example
Query
Response
:MEASure?
:MEASURE +2.345E-03,1 (Headers : ON)
+2.345E-03,1 (Headers : OFF)
The example of response data is shown below :
Measurement valueJudgement
2.345 mA FAIL
Error
An execution error occurs in the following cases :
• When the measurement method is set to "automatic measurement"
• When the measurement mode is not selected
Note
• Use this command after executing the :MODE command to activate the mea-
surement mode.
• When [MEASure?] command is transmitted before the appropriate measure-
ment range is selected in the Auto range, there is the case that the right mea-
surement value is not received by PC
