8.7 Command Message Description
229
8
Chapter 8 Controlling the Instrument From a Computer
Queries the content of a panel
Syntax
Query
Response
:SYSTem:FILE? <numerical value>
<numerical value> = 1 to 30 (NR1)
<character value 1>,<character value 2>,<character value 3>,<character value
4>,<character value 5>,
<numerical value 1>,<numerical value 2>,<numerical value 3>,<numerical
value 4>,<numerical value 5>,<numerical value 6>...
<character value 1> = Equipment name
<character value 2> = Control number
<character value 3> = Grounding class
CLA1 : Class-I equipment
CLA2 : Class-II equipment
INT : Internally powered equipment
<character value 4> = Applied part
B : Type B applied part
BF : Type BF applied part
CF : Type CF applied part
(Returns 0 for network A, C, D, E, F or G)
<character value 5> = Network
A : Network A
B1 : Network B1(only ST5540)
C : Network C
D : Network D
E : Network E
F : Network F
B2 : Network B2(only ST5540)
G : Network G
<numerical value 1> = Measurement mode
When network A, D, E, or F is selected
0 : Earth leakage current
1 : Enclosure - Earth leakage current
2 : Enclosure - Enclosure current
3 : Enclosure - Line leakage current
19 : Free current (only network A)
When network C or G is selected
0 : Earth leakage current
8 : Touch current Enclosure - Earth
9 : Touch current Enclosure - Enclosure
10 : Touch current Enclosure - Line
When network B1 is selected(only ST5540)
0 : Earth leakage current
1 : Enclosure - Earth leakage current
2 : Enclosure - Enclosure current
4 : Patient leakage current I
5 : Patient leakage current II
6 : Patient leakage current III
7 : Patient auxiliary current
19 : Free current
