8.7 Command Message Description
230
When network B2 is selected(only ST5540)
0 : Earth leakage current
7 : Patient auxiliary current
8 : Touch current Enclosure - Earth
9 : Touch current Enclosure - Enclosure
11 : Patient leakage current Patient connection - Earth
12 : Patient leakage current SIP/SOP
13 : Patient leakage current F-type applied part
14 : Patient leakage current Metal accessible part
15 : Total patient leakage current Patient - Earth
16 : Total patient leakage current SIP/SOP
17 : Total patient leakage current F-type applied part
18 : Total patient leakage current Metal accessible part
19 : Free current
<numerical value 2> = Measurement method
0 : Manual
1 : Automatic
<numerical value 3> = Target current
When network A is selected
0 : AC+DC, 1 : AC, 2 : DC,
3 : ACpeak (only Free current)
When network B1 is selected(only ST5540)
0 : AC+DC, 1 : AC, 2 : DC,
3 : ACpeak (only Free current)
(0 except for Patient leakage current I, Patient auxiliary current)
When network C, D, E, F or G is selected
0 : AC+DC, 1 : AC, 2 : DC, 3 : ACpeak
When network B2 is selected (only ST5540)
0 : AC+DC, 1 : AC, 2 : DC
3 : ACpeak (only Free current)
(0 except for Patient auxiliary current/Patient leakage current
Patient connection - Earth, Patient leakage current SIP/SOP, Total
patient leakage current Patient - Earth, Total patient leakage cur-
rent SIP/SOP)
<numerical value 4> = Measurement range
AC, AC+DC, DC
0 : Auto range
1 : 50.00 mA range
2 : 5.000 mA range
3 : 500.0 A range
4 : 50.00 A range
ACpeak
0 : Auto range
1 : 100.0 mA range
2 : 10.00 mA range
3 : 1.000 mA range
4 : 500.0 A range
<numerical value 5> = Filter
When network A is selected
0 : OFF, 1 : ON
When network B1 or B2 is selected
0 : OFF, 1 : ON
When network C is selected
0 : OFF, 2 : ON1(U2), 3 : ON2(U3), 4 : ON1(U1), 5 : ON2(U1)
When network D, E, F or G is selected
0 : OFF
<numerical value 6> = Allowable value date in normal condition(NR3)(unit : A)
<numerical value 7> = Allowable value in
Single-fault condition(NR3)(unit : A)
Queries the content of a panel
