8.7 Command Message Description
231
8
Chapter 8 Controlling the Instrument From a Computer
*
*
*
*
<numerical value 8> = Normal condition allowable value to use when making
DC measurements(NR3)(unit : A)
<numerical value 9> = Single fault condition allowable value to use when mak-
ing DC measurements(NR3)(unit : A)
<numerical value 10> = Allowable value data for normal condition (lower limit)
On/Off
0 : OFF
1 : ON
<numerical value 11> = Allowable value for single-fault condition (lower limit)
On/Off
0 : OFF
1 : ON
<numerical value 12> =Allowable value (lower limit) On/Off of normal condition
during DC measurements
0 : OFF
1 : ON
<numerical value 13> =Allowable value (lower limit) On/Off of single fault condi-
tion during DC measurements
0 : OFF
1 : ON
<numerical value 14> = Equipment under test status
0 : Normal condition
1 : Single-fault condition
(Disconnection of one wire in power line)
2 : Single-fault condition
(
Disconnection of protective earth conductor)
3 : Single-fault condition
(Application of 110% voltage : Positive phase)
4 : Single-fault condition
(Application of 110% voltage : Negative phase)
5 : Single-fault condition (line voltage application : L)
6 : Single-fault condition (line voltage application : N)
<numerical value 15> = Power supply polarity
0 : Positive phase
1 : Negative phase
(0 for
the setting of equipment under test is internally powered
equipment, Enclosure - Line leakage current, Touch current Enclo-
sure - Line)
<numerical value 16> = Other 110% voltage application
0 : Application of 110% voltage : none
1 : Application of 110% voltage : Positive phase
2 : Application of 110% voltage : Negative phase
(0 for ST5541)
<numerical value 17> =
Specific 110% voltage application
0 : Application of 110% voltage : none
1 : Application of 110% voltage : Positive phase
2 : Application of 110% voltage : Negative phase
(0 for ST5541)
Queries the content of a panel
