8.7 Command Message Description
232
<numerical value 18> = Switch
0 : S10=OFF, S12=OFF, S13=OFF
1 : S10=ON, S12=OFF, S13=OFF
2 : S10=OFF, S12=ON, S13=OFF
3 : S10=ON, S12=ON, S13=OFF
4 : S10=OFF, S12=OFF, S13=ON
5 : S10=ON, S12=OFF, S13=ON
(0 for ST5541)
<numerical value 19> = Measurement item in automatic measurement
1 to 4095 (NR1)
<numerical value 20> = Measurement item in automatic measurement2
0 to 63(NR1)
<numerical value 21> = Measuring time in automatic measurement
(NR1)(unit : s)
<numerical value 22> = Wait time in automatic measurement(delay a)
(NR1)(unit : s)
<numerical value 23> = Wait time in automatic measurement(delay b2)
(NR1)(unit : s)
<numerical value 24> = Wait time in automatic measurement(delay c)
(NR1)(unit : s)
<numerical value 25> = Wait time in automatic measurement(delay b1)
(NR1)(unit : s)
Queries the content of a panel
128 64 32 16 8 4 2 1
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Not used
Negative
phase
Positive
phase
Applica-
tion of
110%
voltage
(Negative
phase)
Applica-
tion of
110%
voltage
(Positive
phase)
Discon-
nection of
protective
earth con-
ductor
Discon-
nection of
one wire
in power
line
Normal
32768 16384 8192 4096 2048 1024 512 256
bit 15 bit 14 bit 13 bit 12 bit 11 bit 10 bit 9 bit 8
Not used Not used Not used Not used
Applica-
tion of line
voltage N
Applica-
tion of line
voltage L
AC DC
128 64 32 16 8 4 2 1
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
Not used Not used
Specific
110% volt-
age appli-
cation(Neg
ative
phase)
Specific
110% volt-
age appli-
cation(Posi
tive phase)
Not used
Other Ap-
plication
of 110%
voltage
(Negative
phase)
Other
Applica-
tion of
110%
voltage
(Positive
phase)
Other
Applica-
tion of
110%
voltage
(none)
32768 16384 8192 4096 2048 1024 512 256
bit 15 bit 14 bit 13 bit 12 bit 11 bit 10 bit 9 bit 8
Not used Not used Not used Not used Not used Not used Not used Not used
