8.7 Command Message Description
233
8
Chapter 8 Controlling the Instrument From a Computer
Function
Query Returns the content of the panel of the specified number.
Example
Query
Response
:SYSTem:FILE? 1
:SYSTEM:FILE ABC,NO-111,CLA1,BF,B2,12,0,2,0,1,
+100.0E-06,+500.0E-06,+10.00E-06,+50.00E-06,
0,0,1,0,1,1,2,0,1,0,0,0,0,0,0,0(Headers: ON)
ABC,NO-111,CLA1,BF,B2,12,0,2,0,1,+100.0E-06,
+500.0E-06,+10.00E-06,+50.00E-06,0,0,1,0,1,1,2,
0,1,0,0,0,0,0,0,0 (Headers: OFF)
The following settings have been made:
<Equipment name> : ABC
<Control number> : NO-111
<Grounding class> : Class-I equipment
<Applied part> : BF-type applied
parts
<Network> : Network B2
<Measurement mode> : Patient leakage
current:SIP/SOP
<Measurement method> : Manual
<Target current> : DC
<Measurement range> : Auto range
<Filter> : ON
<Allowable value in normal condition
(upper limit)> : 0.1 mA
<Allowable value in single-fault condition
(upper limit)> : 0.5 mA
<Normal condition allowable value
(upper limit, DC measurements)> : 0.01mA
<Single fault-condition allowable value
(upper limit, DC measurements
)> : 0.05mA
<Allowable value in normal condition
(lower limit ON/OFF)> : OFF
<Allowable value in single-fault condition
(lower limit ON/OFF)> : OFF
<Normal condition allowable value
(lower limit ON/OFF, AC measurements)> : ON
<Single fault-condition allowable value
(lower limit ON/OFF, AC measurements)> : OFF
<Equipment under test status> : Single-fault
condition
Disconnection of one wire in power line)
<Power supply polarity> : Negative phase
<Other 110% voltage application> : 110% voltage
application:
Negative phase
<Specific 110% voltage application> : 110% voltage
application:None
<Switch> : S10=ON,S12=OFF,S13=OFF
<Measurement item in automatic measurement> : None
<Measurement item in automatic measurement2> : None
<Measuring time in automatic measurement> : None
<Wait time in automatic measurement(delay a)> : None
<Wait time in automatic measurement(delay b2)> : None
<Wait time in automatic measurement(delay c)> : None
<Wait time in automatic measurement(delay b1)> : None
Error
If the designated panel number does not conform to the specified range, an
execution error occurs.
Note
Returns 0 in the following cases:
<numerical value 11>(Equipment under test status)<numerical value
12>(Power supply polarity) in automatic measurement
<numerical value 13>(Other 110% voltage application)<numerical value
14>(
Specific 110% voltage application)<numerical value 15>(Switch)
<numerical value 16> to <numerical value 22> in manual measurement
When there is no data
Queries the content of a panel
