Hitachi Unified Storage Hardware Service Guide
Power Unit for CBLD Controller Box
•
Power Unit for DBX Drive Box
•
•
Legend Component Color Description
¶
Power Socket Connects to DC power source.
?
ALM Red ON = Power Unit is experiencing trouble. Visit
the HDS Support Portal at portal.hds.com.
?
RDY Green ON = Power Unit is operating normally.
Legend Component Color Description
¶
ALM Red ON = Power Unit is experiencing trouble. Visit
the HDS Support Portal at portal.hds.com.
?
RDY Green ON = Power Unit is operating normally.
?
Power Socket Connects to AC power source.
