Upgrading a Hitachi Unified Storage 130 system 15–9
Hitachi Unified Storage Hardware Service Guide
3. In the next page:
a. Enter the following default IP address in the Specific IP Address or
Array Name fields for each storage system management port.
Controller 0: type 192.168.0.16
Controller 1: type 192.168.0.17
b. In the Using Ports area, select whether the ports are secure,
nonsecure, or both.
c. Click Next.
4. In the next page:
a. Enter a storage system name in the Array Name field.
b. Click Next.
5. Click Finish.
6. At the Arrays page, confirm that the status of the Hitachi Unified Storage
system is Normal.
Locking extra-cost options
If one or more extra-cost (or “priced”) options other than Dynamic
Provisioning and Data Retention Utility are used with the CBSL or CBSS,
uninstall (or “lock”) the option prior to performing the upgrade. This
procedure requires you to use Hitachi Storage Navigator Modular 2 and the
key code or key file supplied with the option.
If the CBSL or CBSS does not have priced options, skip this procedure and
go to Registering the Hitachi Unified Storage system on page 15-7.
1. Record the settings of the option for future reference.
2. At the Hitachi Storage Navigator Modular 2 Arrays page, check the
storage system that has the extra-cost option.
3. Press the Ctrl, Shift, and E keys at the same time to switch Hitachi
Storage Navigator Modular 2 to Maintenance Mode. Confirm that
Maintenance Mode appears next to Operation Mode on the Arrays
page (see Figure 15-1 on page 15-10).
NOTE: If your management console is directly connected to a
maintenance port, enter the default IP address just for that port
(Controller 0 = 10.0.0.16, Controller 1 = 10.0.0.17).
NOTE: If Maintenance Mode does not appear next to Operation Mode,
click a blank area in the Arrays page (away from GUI components such as
buttons and check boxes), and then press the Ctrl, Shift, and E keys at the
same time.
