Hitachi CBXSS - Rear Panel; Top View

Hardware description 2–25
Hitachi Unified Storage Hardware Service Guide
Rear panel
•
Figure 2-30: DBW rear panel
Top view
•
Figure 2-31: DBW top view
•
Legend:
¶
I/O Module (ENC)
See I/O Module (ENC) for DBW Drive Box on page 2-57.
?
Fan Module
See DBW Fan Module on page 2-60.
?
Power Unit
See Power Unit for DBW Drive Box on page 2-58.
¶
?
?
Drive
