2–14 Hardware description
Hitachi Unified Storage Hardware Service Guide
Rear panel
•
Figure 2-16: CBL / CBLD Controller Box rear panel
Legend:
¶
Two Controllers
Controller 0 (left) and Controller 1 (right)
?
Management Module
See Management Module for CBL/CBLD Controller Box on page 2-53.
?
Drive I/O Module
See Drive I/O Module for CBL/CBLD Controller Box on page 2-54.
?
Host I/O Modules
See Host I/O Modules for CBLCBLD Controller Box on page 2-55.
?
Power Unit
See Power Unit for CBL Controller Box on page 2-46.
¶ ¶
?
???
?
?
?
NOTE: The CBLD rear panel is identical to the figure above, except the AC
receptacles are replaced by receptacles for accommodating DC power.
