Rear panel of CBL/CBLD Controller Box
Figure 2-32: Modules on rear of CBL Controller Box
Host I/O Module
Drive I/O Module
Management Module
Management
Module
UPS
Drive I/O
Module
Host I/O Module
Fibre Channel
Interface Module
10 Gb iSCSI
Interface Module
