Copying and installing firmware
The firmware is located in a compressed (zip) file under
Firmware\program\microprogram on the supplied DVD. Copy it to the
following location on the maintenance PC:
C:\diskarray-microprogram\microprogram
After copying the firmware file, use the following procedure to install the
firmware on the CBSL/CBSS. You perform this configuration two times.
1. At the Hitachi Storage Navigator Modular 2 Arrays page, check the
storage system on which you will install the firmware.
2. Press the Ctrl, Shift, and E keys at the same time to switch to
Maintenance Mode. Confirm that Maintenance Mode appears next to
Operation Mode on the Arrays page (see Figure 15-1 on page 15-10).
3. Under the Array Name column, confirm that the name of the Hitachi
Unified Storage system is checked in the Arrays page.
4. In the middle pane, click Settings > Firmware.
5. On the right side of the Firmware page, find the firmware revision shown
next to Revision and record it below
Record the local file revision here:......................
6. Click the Update Firmware button. The Update Firmware page
appears, with the Basic tab displayed.
Table 15-2: DVD File Structure
Root level First subfolder Second subfolder
manual hostInst manual file
UG
program microprogram Firmware zip file
DFJavaSetup.exe
(Java setup file)
—
