Replacing a cache backup battery 5–5
Hitachi Unified Storage Hardware Service Guide
Figure 5-1: Replacing a cache backup battery
on a CBXSS/CBXSL/CBSS/CBSL
(b) Replacing a Cache Backup Battery
Cable clamp
Connecter
Cable
Cache Backup Battery
Screw
(blue)
Cover
Latch
Lever
Cache Backup Battery
Cable holder
Latch
Latch and lever operation of Power Unit
Latch
Lever
Power Unit #0
Power Unit #1
(a) Removing a Power
Unit
LED name
