Hitachi IJ UX Service Manual

3-24
[EZJ127A board external view]
[EZJ127B board external view]
[Usage for the External connection terminal block 1 (TB1)]
- Applicable cable size : AWG26 to 16 (Φ0.5to 1.3)
- Wire covering to be stripped : 8 to 9 mm
Two fixing screws
Two fixing screws
TP6
SW1
LED1, LED4，LED19
Lot number:
(Last digit: B)
Terminal block:
TB1 (13 pins)
SW1
Two fixing screws
SW2
Two fixing screws
LED1 – LED23
TP6
Terminal block: TB1
Lot number:
(Last digit: A)
Terminal block
(TB1)
(1) Push
(2) Insert
Twist the
wires
