Hitachi IJ UX Service Manual

2-59
2.22 Dimensions for Tapered-Printhead Printing
●When it is necessary to place the printhead close to the conveyer or when the milk carton is printed,
refer to the following figures for the reference dimensions for the tapered-printhead printing.
１）In case that Tapered Printhead is placed close to Belt Conveyor
The bottom height of printing area, measured from the Belt conveyor *1.
・Print head angle:20°, Print distance：20mm、Target distance from the belt conveyor：4mm
２）In case the Tapered Printhead is placed for Milk Carton.
・Distance between the Tapered Printhead and Milk Carton：4mm
a)The print head is set levelly
b）The Print head is set with an angle
(*1)
(*1) (*1)
(*1)
(*2)
(*2)
(*2)
(*2)：Print distance（From printing surface to print head.）
<Inverted>
Previous Model
Model UX
<Upright>
<Upright>
Model UX
Previous Model
<Inverted>
<Inverted>
<Upright>
<Upright>
Milk
Carton
Milk
Carton
Milk
Carton
Belt conveyor
Belt conveyor
Belt conveyor
Belt conveyor
