2-8
2.3.2 Charging voltage confirmation
Voltage for confirmation of charging voltage is output for 3 minutes.
Be sure to perform this confirmation when performing the board exchange (EZJ126 and 125).
This confirmation is performed in a state the IJ printer “stop” state.
1 Press Adjustment/operational checkout on the maintenance menu.
If Adjustment/operational checkout is not displayed on the maintenance menu, set the
service personnel maintenance mode on the login user selection screen.
The adjustment/operational checkout menu is then displayed.
2 Press Charge voltage confirmation.
The Charge voltage confirmation screen is then displayed.
The voltage for confirmation is output for 3 minutes
.
For information on changing to the service personnel maintenance mode,
refer to “2.1 Setting of service personnel maintenance mode.”
Manual
Start
up
HOME
Back
Adjust./oper. checkout
Excitation
adjustment
Charge voltage
confirmation
Phase margin test
Heating unit
confirmation
Auto-phase gain
adjustment
Level sensor
confirmation
[
Stop ]
2015.07.07 12:45
Com=0
Charge voltage confirmation
Adjust./oper. checkout
<Charge voltage confirmation>
Execution takes 3 minutes.
Abort
Proc. status: In progress
[Stop ]
2015.07.07 12:45
Com=0
Abort
