Hitachi IJ UX Service Manual

2-4
2.2 System environment setup
●The setting with respect to the system environment of the IJ printer is performed.
①
Ink type ② Cable length
③
Nozzle size ④ Ink temperature correction
⑤
Excitation frequency ⑥ Excitation curve
⑦
Ambient temperature upper limit ⑧ Ambient temperature lower limit
⑨
Excitation setting (Max.)
●A “USB memory containing system data” is needed to set nozzle size.
●This setting is performed in the IJ printer "Stop" state.
1 The maintenance menu is displayed.
If Prev. menu Next menu is not displayed on the maintenance menu, set the service
personnel maintenance mode on the login user selection screen.
2 Press System environment setup on the second page of the maintenance
menu.
The system environment setup screen is then displayed.
3 Modify the setting values.
*) Note: This item is automatically reset to the initial value when ink type is changed.
4 When setup is complete, press Back.
The screen returns to the maintenance menu.
[Note]
When change the ink type, Ink concentration control switch to enable on circulation environment
screen.
Set disable when does not use the Ink concentration control function on circulation environment
screen.
For information on changing to the service personnel maintenance mode,
refer to “2.1 Setting of service personnel maintenance mode.”
*)
Back
Back
Excitation freq.
68.9
Ink type
001
Cable length
4
Nozzle diameter
65
Ink temperature correction
disable
Excitation curve
01
Ambient temp. upper lim.
45
Ambient temp. lower lim.
00
Excitation V-ref. (Max)
19
(kHz; standard value:
68.9)
(1067K )
(m)
(standard value: 0)
(19-27)
enable
System env. setup
+
-
+
-
[Stop ]
2015.07.07 12:45
Com=0
( m)
( ; 40
-50； standard value:45)
( ; 0
- 5； standard value: 0)
