Hitachi IJ UX Service Manual

3-41
Reference
number
Name Contents
LED26 Data message number signal
bit 10(NPN)
When the data message number signal bit 10
input (NPN) is ON, it is lighted.
LED27 Data message number signal
bit 10(PNP)
When the data message number signal bit 10
input (PNP) is ON, it is lighted.
LED28 Data message number signal
bit 11(NPN)
When the data message number signal bit 11
input (NPN) is ON, it is lighted.
LED29 Data message number signal
bit 11(PNP)
When the data message number signal bit 11
input (PNP) is ON, it is lighted.
LED30 Strobe signal (NPN) When the strobe signal input (NPN) is ON,
it is lighted.
LED31 Strobe signal (PNP) When the strobe signal input (PNP) is ON,
it is lighted.
LED36 Signal during calendar Updating
(PNP)
When the Signal during calendar Updating (PNP)
is ON, it is lighted.
LED37 Signal notifying
Completion of
signal input (PNP)
When the Signal notifying
Completion of signal
input (PNP) is ON, it is lighted.
LED39 Signal during calendar Updating
(NPN)
When the Signal during calendar Updating
(NPN) is ON, it is lighted.
LED40 Signal notifying
Completion of
signal input (NPN)
When the Signal notifying
Completion of signal
input (NPN) is ON, it is lighted.
