Hitachi IJ UX Service Manual

4-47
Symptom
Probable cause
Check method
Repairing method
No
recovery
The recovery
pump
malfunctions.
Follow the same descriptions as those of “The supply pump
malfunctions ".
The solenoid
valve
malfunctions.
* MV3
malfunctions.
When “Open” is
executed on
“Solenoid
Valve/Pump Test”
screen, no operation
sound is produced.
Replace or repair the
solenoid valve (MV3).
Refer to “4.15
Repairing method
when the circulation
route is dry or sticks”.
The recovery
route clogs.
Clogging in
the recovery
filter
A lot of foreign
materials stick on
the recovery filter.
Replace the recovery
filter.
Clogging in
the pipe or
joint
Suck is performed
when the tube
connected to the
recovery filter is
removed.
Press makeup into the
end of the recovery
filter connecting tube
by applying pressure
with a hand pump.
- Hand pump
specifications
Part name:
Nozzle cleaning
assembly
Part No.: 451000
A
viscometer
error
occurs.
The
circulation
pump
malfunctions.
Follow the same descriptions as those of “The supply pump
malfunctions ".
The solenoid
valve
malfunctions
* MV4
malfunctions.
When “Open” is
executed on
“Solenoid
Valve/Pump Test”
screen, no operation
sound is produced.
Replace or repair the
solenoid valve (MV4
).
Refer to “4.15
Repairing method
when the circulation
route is dry or sticks”.
The
circulation
route clogs.
Clogging in
the pipe or
joint
The nozzle can be
flushed reversely
and MV4 can be
operated normally.
Refer to “4.15
Repairing method
when the circulation
route is dry or sticks”.
Viscometer
failure
In cases other than three cases
above.
Replace the
viscometer”.
Backwash
is
impossible.
The
circulating
pump
malfunctions.
Follow the same descriptions as those of “The supply pump
malfunctions ".
The solenoid
valve
malfunctions.
* MV5
malfunctions.
When “Open” is
executed on
“Solenoid
Valve/Pump Test”
screen, no operation
sound is produced.
Replace or repair the
solenoid valve (MV5).
Refer to “4.15
Repairing method
when the circulation
route is dry or sticks”.
The
pressure
drops
during
normal
operation.
The solenoid
valve
malfunctions.
* MV2
malfunctions.
When “Open” is
executed on
“Solenoid
Valve/Pump Test”
screen, no operation
sound is produced.
Replace or repair the
solenoid valve (MV2
).
Refer to “4.15
Repairing method
when the circulation
route is dry or sticks”.
