Hitachi UX Twin Nozzle Service Manual

3-46
Reference
number
Name
Contents
LED26
Data message number signal
bit 10(NPN)
When the data message number signal bit 10
input (NPN) is ON, it is lit.
LED27
Data message number signal
bit 10(PNP)
When the data message number signal bit 10
input (PNP) is ON, it is lit.
LED28
Data message number signal
bit 11(NPN)
When the data message number signal bit 11
input (NPN) is ON, it is lit.
LED29
Data message number signal
bit 11(PNP)
When the data message number signal bit 11
input (PNP) is ON, it is lit.
LED30
Strobe signal (NPN)
When the strobe signal input (NPN) is ON,
it is lit.
LED31
Strobe signal (PNP)
When the strobe signal input (PNP) is ON,
it is lit.
LED36
Signal during calendar Updating
(PNP)
When the Signal during calendar Updating (PNP)
is ON, it is lighted.
LED37
Signal notifying Completion of
signal input (PNP)
When the Signal notifying Completion of signal
input (PNP) is ON, it is lit.
LED39
Signal during calendar Updating
(NPN)
When the Signal during calendar Updating
(NPN) is ON, it is lit.
LED40
Signal notifying Completion of
signal input (NPN)
When the Signal notifying Completion of signal
input (NPN) is ON, it is lit.
