2-4
2.2 System environment setup
The setting with respect to the system environment of the IJ printer is performed.
Ink type Cable length Ink temperature correction
Excitation freq. Excitation curve Ambient temp. upper lim.
Ambient temperature lower lim. Excitation V-ref. (Max)
This setting is performed with the IJ printer in "Stop" state.
1 The maintenance menu is displayed.
If Prev. menu Next menu is not displayed on the maintenance menu, set the service personnel
maintenance mode on the login user selection screen.
2 Press System environment setup on the second page of the maintenance
menu.
The system environment setup screen is then displayed.
3 Modify the setting values.
*) Note: This item is automatically reset to the initial value when ink type is changed.
4 When setup is complete, press Back.
The screen returns to the maintenance menu.
[Note]
When changing the ink type, Ink concentration control switches to enable on circulation
environment screen.
Set disable on circulation environment screen, when the Ink concentration control function is not
used.
For information on changing to the service personnel maintenance mode,
refer to “2.1 Setting of service personnel maintenance mode.”
*)
