4-77
4.
16 Maintenance work of
intake fan unit
4.
16
.1
Structure o
f In
take f
an unit
4.16.2 Rep
lacement
of
Intake
fan un
it
1
Turn of
f the
power.
2
Loosen the
thum
bscrew and remo
ve the Inta
ke fan
cover.
3
Remove the A
ir filter.
[Note]
The
Air filter has f
ront and
rear face
s.
Set the f
ilter with red-mark be
ing invisible.
Intake fan cover assem
bly
Intake fan
Thum
bscrew
Air
filter
Intake fan unit assem
bly
Intake fan cover
Air filter
(Red-m
ark in rear)
Intake fan cover
Thum
bscrew (2 locations)
210
212
