2-25
3 The measurement is completed in four minutes, and coefficient (calculated value)
will be displayed.
If “Fault” is displayed for “Proc. Status, follow the instructions given in
“4.12 Troubleshooting when Fault Occurs in Viscometer.”
4 Press OK.
If the OK key is pressed when Proc. Status” is Ended, the coefficient will be
registered, and the circulation control screen will be displayed.
2.6.2 Operation test of viscometer
This function allows you to check the viscometer operation and measure the current ink
viscosity. Note that this operation test is not to determine the coefficient.
It is not necessary to use new ink for operation test.
Coefficient
OK
[Note]
The coefficient value will not be registered when Cancel is pressed instead of OK key.
[Standard value of the viscometer calibration] 1200 to 2200
*The value stated above is a reference. There will be no problem even if the coefficient
value displayed is other than stated above as long as data of Plunger falling time keeps
within a similar range.
OK
Cancel
<the previous calibration>
Exec.time 2018/07/07 11:30
< the current calibration >
Exec.time 2018/07/07 12:45
Proc. Status: Ended
Viscometer calibration
HOME
[Stop ]
2018.07.07 12:45
Com=0
Plunger falling time
Plunger falling time
1st
2nd
5th
Average
3rd
4th
Inside temperature XX ( )
Standard X. XXX (mPas)
X.XX (sec)
X.XX (sec)
X.XX (sec)
X.XX (sec)
X.XX (sec)
X.XX (sec)
1st
2nd
5th
Average
3rd
4th
Inside temperature XX ( )
Standard X. XXX (mPas)
X.XX (sec)
X.XX (sec)
X.XX (sec)
X.XX (sec)
X.XX (sec)
X.XX (sec)
Coefficient XXXX
Coefficient XXXX
Ink viscosity XXX
When updating coefficient, press [OK].
