5-2
5.2 Cable running direction
The cable running direction can be changed as shown in the following figures.
The customer should not attempt to run the cable himself/herself.
The cable should be run by a service technician.
１ Remove the 4 fastening screws.
Pull out the coupling approximately
by 10 mm.
２ Turn the cable by 90°.
３ Tighten the 4 fastening screws.
To Next Page
