Hitachi UX Twin Nozzle - Solenoid Valves Replacement Procedure

4-14
4.5 Solenoid Valve Replacement Procedure
[Caution]・Work contents differ according to the solenoid valve No. to be replaced.
・If the solenoid valve does not operate, conduct the replacement work with particular attention to
dripping.
1 Perform the following preparation for each solenoid valve that you are to replace.
Solenoid
valve No.
When the solenoid valve is working
When the solenoid valve is not working
MV1
Execute “Ink drainage”.
Drain the ink of the main ink tank from
the drain tube.
MV2
(1) Remove the tube connection
block of the ink reservoir.
(2)Turn on the pump, MV2, and
MV6 in this order for about one
minute, and then turn them off.
(Solenoid/Pump Test screen)
No operation is required.
(Pay attention to ink dripping.)
MV3
Execute “Gutter Cleaning”.
No operation is required.
(Pay attention to ink dripping.)
MV4
Execute “Ink drainage”.
No operation is required.
(Pay attention to ink dripping.)
MV5
Execute “Nozzle backwash 1”.
No operation is required.
(Pay attention to ink dripping.)
MV6
Execute “Ink drainage”.
No operation is required.
(Pay attention to ink dripping.)
MV7
Execute “Ink drainage”.
Drain the ink of the main ink tank from
the drain tube.
MV8
Execute “Pressure relief”.
No operation is required.
(Pay attention to makeup dripping.)
MV11
No operation is required.
(Pay attention to makeup dripping.)
No operation is required.
(Pay attention to ink dripping.)
MV12
Execute “Pressure relief”.
No operation is required.
(Pay attention to ink dripping.)
MV23
Execute “Gutter Cleaning”.
No operation is required.
(Pay attention to ink dripping.)
MV25
Execute “Nozzle backwash 2”.
No operation is required.
(Pay attention to ink dripping.)
MV28
Execute “Pressure relief”.
No operation is required.
(Pay attention to ink dripping.)
2 Turn off the power supply.
【Work from the front】
3 Perform “4.1.2 Access to the parts on the front side of the equipment”.
【Work from the rear】
3 Perform “4.1.3 Access to the parts on the rear side of the equipment”.
4 Remove the connector of the solenoid valve to be replaced.
・ Parts inside the solenoid valve (diaphragm, etc.) cannot be replaced separately. In the case of
part failure, replace the entire solenoid valve.
・ The coil mold of the solenoid valve (black resin portion) is not resistant to solvents. Do not
immerse the coil mold in solvent. The coil mold however can be wiped gently with solvent.
