2.5 Download
●This function is used for upgrading the program.
●The program on the EZJ128 and EZJ133 boards is downloaded from the USB memory.
●A “USB memory containing system data” is required.
●This function is executed with the IJ printer in “Stop” state.
●There are two ways to download the program. The effect is the same for either way.
Download method
Method
Features
Merits
Mount the USB and
turn the power on.
Compares version of the
programs in the IJ printer
memory with ones in the USB
memory and downloads
different programs only.
Only downloads programs of
different version, so processing
is completed faster.
Execute from the
download screen.
Downloads all programs.
You can confirm version of each
program on the screen.
1 The maintenance menu is displayed.
If Prev. menu Next menu is not displayed on the maintenance menu, set the service personnel
maintenance mode on the login user selection screen.
2 Mount “USB memory containing system data”.
For precautions when replacing the EZJ128 board, refer to “3.2.1 EZJ128 board.”
For precautions when replacing the EZJ133 board, refer to “3.3.1 EZJ133 board.”
●Be sure to perform program download when replacing the EZJ128 and EZJ133 boards.
The boards are initialized and the program is updated by downloading. For information
concerning replacement of the EZJ133 and EZJ128 boards, refer to “3.2.1 EZJ128 board.”
and “3.3.1 EZJ133 board".
For information on changing to the service personnel maintenance mode, refer
to “2.1 Setting of service personnel maintenance mode.”
USB memory containing system
data
