Hitachi UX Twin Nozzle - Access to the Parts on the Rear Side of the Equipment

4-6
Fixing screws
4.1.3 Access to the parts on the rear side of the equipment
(1) Access method from the front
1 Perform “4.1.2 Access to the parts on the front side of the equipment” and pull the
reservoir unit out.
2 Remove the fixing screws (2 pieces) of the unit door and open the unit door.
[Caution] Take care not to cause the tubes to be caught.
Unit door
Unit door
