Hitachi UX Twin Nozzle Service Manual

3-56
- Regarding the wire harness clamping position inside the maintenance cover,
refer to following list.
[UX model wire harness list]
Mark
Part No.
DWG No.
Name
Single/Twin compatibility
Yes or no
A
－
3J83P49331
Card connector UX(N)
Y
B
－
2N4ZL2142A
LED harness UX
Y
C
－
1N4ZE0065A
Controller harness UX
Y
D
－
2N4ZL9644A
Relay board harness UXT2
N
E
－
2N4ZL8272A
Relay board harness UXT
N
F
451882
2N4ZH9186A
Sub switch harness assembly
Y
G
451874
1N4ZE0063A
Inlet harness UX
Y
H
451890
2N4ZH9193A
Main switch harness assembly
Y
I
451881
2N4ZH9191A
Multiple power supply harness
assembly
Y
J
－
1N4ZE3750A
MGV harness UXT
N
K
－
2N4ZL2146A
Level sensor harness UX
Y
L
－
1N4ZE0501A
Sensor harness UX
Y
M
－
3N4ZM4183A
High-voltage harness H
assembly
Y
N
－
2N4ZL2144A
High-voltage harness S UX
Y
O
－
1N4ZE0066A
I/O harness UX
Y
P
－
2N4ZL2139A
Connection harness MV UX
Y
Q
－
2N4ZL2140A
Connection harness S UX
Y
R
－
1N4ZE0067A
OP I/O harness UX
OP
S
－
2N4ZL2154A
Relay output harness assembly
Y
T
－
2N4ZL8304A
Connection harness MV-UXT
N
U
－
2N4ZL8305A
Connection harness -UXT
N
V
－
2N4ZL4975A
RFID reader harness
Y
W
－
2N4ZL8007A
Pressure sensor harness
Y
X
－
2N4ZL9615A
Relay connection harness UXT
N
Y
－
2N4ZL2137B
Power supply harness UXT
N
Z
－
2N4ZL8306A
High-voltage harness H-UXT
N
AA
－
2N4ZL9014A
High-voltage harness UXT
N
AB
－
1N4ZE0502A
MGV harness UX
Y
AC
－
2N4ZL5401A
Back light harness UX
Y
AD
－
2N4YM08661
LAN relay harness
N
AE
×
3B1JM3935E
Coaxial excitation cable CJ6
N
AF
×
3B1JM3936E
Coaxial Charge voltage cable CJ6
N
