Hiwin E1 Series User Manual

E1 Series Servo Drive User Manual Parameters
HIWIN MIKROSYSTEM CORP. 15-21
MD09UE01-1910
Pt No.
Pt232
Size 2
Setting
Range
-2
30
+1~+2
30
-1 Default 0
Name
Stop position of
position trigger
function
Unit 1 control unit
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt233
Size 2
Setting
Range
0~4095 Default 100
Name
Pulse output width of
position trigger
function
Unit 20 ns
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
Pt No.
Pt281
Size 2
Setting
Range
2000~1073741824 Default 100000
Name
Encoder output
resolution
Unit
1 pulse edge/100
mm
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
Pt No.
Pt300
Size 2
Setting
Range
150~3000 Default 600
Name
Velocity command
input gain
Unit 0.01 V/rated velocity
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt301
Size 2
Setting
Range
0~10000 Default 100
Name
Internal set velocity
1
Unit Rotary motor: 1 rpm
Applicable
Motor
Rotary
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt234
Size 2
Setting
Range
1~4000 Default 1
Name
Digital signal output
width of position
trigger function
Unit 0.25 ms
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
