Hiwin E1 Series User Manual

E1 Series Servo Drive User Manual Parameters
15-20 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
Pt No.
Pt218
Size 2
Setting
Range
1~100 Default 1
Name
Command pulse
input multiplier
Unit x 1
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt22A
Size
2
Setting
Range
0000~1000 Default 0000
Name
Full-closed loop
control selection
Unit -
Applicable
Motor
Rotary
Effective
After power on
Category
Setup
Reference
-
Description
t.X Reserved (Do not modify.)
t.X Reserved (Do not modify.)
t.X Reserved (Do not modify.)
t.X
Velocity feedback selection during full-closed loop control
0 From motor encoder
1 From external encoder
Pt No.
Pt230
Size 2
Setting
Range
-2
30
+1~+2
30
-1 Default 0
Name
Start position of
position trigger
function
Unit 1 control unit
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt231
Size 2
Setting
Range
0~+2
30
-1 Default 0
Name
Output interval of
position trigger
function
Unit 1 control unit
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
