Hiwin E1 Series User Manual

E1 Series Servo Drive User Manual Parameters
HIWIN MIKROSYSTEM CORP. 15-33
MD09UE01-1910
Pt No.
Pt507
Size 2
Setting
Range
0~10000 Default 100
Name
Brake command
output velocity value
Unit 1 rpm
Applicable
Motor
Rotary
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt508
Size 2
Setting
Range
10~100 Default 50
Name
Servo off-brake
command waiting
time
Unit 10 ms
Applicable
Motor
All
Effective
Immediately
Category
Setup
Reference
-
Pt No.
Pt50A
Size 2
Setting
Range
0000~BBBB Default 3210
Name
Input signal selection
1
Unit -
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
Description
t.X
Allocation of servo on input (S-ON) signal Reference
0 Active when CN6-33 (I1) input signal is ON.
-
1 Active when CN6-30 (I2) input signal is ON.
2 Active when CN6-29 (I3) input signal is ON.
3 Active when CN6-27 (I4) input signal is ON.
4 Active when CN6-28 (I5) input signal is ON.
5 Active when CN6-26 (I6) input signal is ON.
6 Active when CN6-32 (I7) input signal is ON.
7 Active when CN6-31 (I8) input signal is ON.
8 Active when CN6-9 (I9) input signal is ON.
9 Active when CN6-8 (I10) input signal is ON.
A The signal is always active.
B The signal is always inactive.
t.X
Allocation of proportional control input (P-CON) signal Reference
0~B The allocation is the same as the one of servo on input (S-ON) signal. -
t.X
Allocation of forward prohibition input (P-OT) signal Reference
0~B
The allocation is the same as the one of servo on input (S-ON) signal.
-
t.X
Allocation of reverse prohibition input (N-OT) signal Reference
0~B The allocation is the same as the one of servo on input (S-ON) signal. -
