E1 Series Servo Drive User Manual Parameters
HIWIN MIKROSYSTEM CORP. 15-35
MD09UE01-1910
Pt No.
Pt50C
Size 2
Setting
Range
0000~BBBB Default BBBB
Name
Input signal selection
3
Unit -
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
Description
t.X
Allocation of motor rotation direction input (SPD-D) signal Reference
0 Active when CN6-33 (I1) input signal is ON.
-
1 Active when CN6-30 (I2) input signal is ON.
2 Active when CN6-29 (I3) input signal is ON.
3 Active when CN6-27 (I4) input signal is ON.
4 Active when CN6-28 (I5) input signal is ON.
5
Active when CN6-26 (I6) input signal is ON.
6 Active when CN6-32 (I7) input signal is ON.
7 Active when CN6-31 (I8) input signal is ON.
8 Active when CN6-9 (I9) input signal is ON.
9 Active when CN6-8 (I10) input signal is ON.
A The signal is always active.
B The signal is always inactive.
t.X
Allocation of internal set velocity 1 input (SPD-A) signal Reference
0~B
The allocation is the same as the one of motor rotation direction input
(SPD-D) signal.
-
t.X
Allocation of internal set velocity 2 input (SPD-B) signal Reference
0~B
The allocation is the same as the one of motor rotation direction input
(SPD-D) signal.
-
t.X
Allocation of zero clamp input (ZCLAMP) signal Reference
0~B
The allocation is the same as the one of motor rotation direction input
(SPD-D) signal.
-
