Hiwin E1 Series User Manual

E1 Series Servo Drive User Manual Parameters
15-38 HIWIN MIKROSYSTEM CORP.
MD09UE01-1910
Pt No.
Pt50F
Size 2
Setting
Range
0000~BBBB Default BBB9
Name
Input signal selection
6
Unit -
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
Description
t.X
Allocation of forced stop input (FSTP) signal Reference
0~B
The allocation is the same as the one of servo drive reset input (RST)
signal.
-
t.X
Allocation of position deviation clear input (CLR) signal Reference
0~B
The allocation is the same as the one of servo drive reset input (RST)
signal.
-
t.X Reserved (Do not modify.)
t.X Reserved (Do not modify.)
Pt No.
Pt511
Size 2
Setting
Range
0000~1111 Default 0000
Name
Input signal inverse
setting 1
Unit -
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
Description
t.X
I1 signal inversion
0
The signal is not inverted.
1 The signal is inverted.
t.X
I2 signal inversion
0
The signal is not inverted.
1 The signal is inverted.
t.X
I3 signal inversion
0 The signal is not inverted.
1 The signal is inverted.
t.X
I4 signal inversion
0 The signal is not inverted.
1 The signal is inverted.
