E1 Series Servo Drive User Manual Parameters
HIWIN MIKROSYSTEM CORP. 15-39
MD09UE01-1910
Pt No.
Pt512
Size 2
Setting
Range
0000~1111 Default 0000
Name
Input signal inverse
setting 2
Unit -
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
Description
t.X
I5 signal inversion
0 The signal is not inverted.
1 The signal is inverted.
t.X
I6 signal inversion
0 The signal is not inverted.
1 The signal is inverted.
t.X
I7 signal inversion
0
The signal is not inverted.
1 The signal is inverted.
t.X
I8 signal inversion
0
The signal is not inverted.
1 The signal is inverted.
Pt No.
Pt513
Size 2
Setting
Range
0000~1011 Default 0000
Name
Input signal inverse
setting 3
Unit -
Applicable
Motor
All
Effective
After power on
Category
Setup
Reference
-
Description
t.X
I9 signal inversion Reference
0 The signal is not inverted.
-
1 The signal is inverted.
t.X
I10 signal inversion Reference
0 The signal is not inverted.
-
1 The signal is inverted.
t.X Reserved (Do not modify.)
t.X
Allocation of input signals Reference
0 Use the default signal allocation.
-
1 Use user-defined signal allocation.
