Hologic thinprep 2000 - Page 124

5A5B
OPERATING INSTRUCTIONS FOR PROCESSING COBAS AMPLICOR™ CT/NG
SAMPLES
5B.12 ThinPrep 2000 Processor Operator’s Manual
4. The slide should now rest on top of the two clamps and under the upper guide block as shown in
Figure 5B-10.
Figure 5B-10 Correct/Incorrect Slide Insertion
LABEL
END
LABEL
END
LABEL
END
Slide properly
placed
Slide skewed to left Slide skewed to right
