HYDRAULIC BRAKE SPECIFICATIONS
Unit: mm (in)
BATTERY/CHARGING SYSTEM SPECIFICATIONS
IGNITION SYSTEM SPECIFICATIONS
ITEM STANDARD SERVICE LIMIT
Front Specified brake fluid DOT 4 –
Brake disc thickness 4.5 (0.18) 3.5 (0.14)
Brake disc runout – 0.30 (0.012)
Master cylinder I.D. 12.700 – 12.743 (0.5000 – 0.5017) 12.755 (0.5022)
Master piston O.D. 12.657 – 12.684 (0.4983 – 0.4994) 12.645 (0.4978)
Caliper cylinder I.D.
(CBF600SA/NA)
Upper 22.650 – 22.700 (0.8917 – 0.8937) 22.712 (0.8942)
Middle 22.650 – 22.700 (0.8917 – 0.8937) 22.712 (0.8942)
Lower 22.650 – 22.700 (0.8917 – 0.8937) 22.712 (0.8942)
Caliper cylinder I.D.
(CBF600S/N)
Upper 25.400 – 25.450 (1.0000 – 1.0020) 25.460 (1.0023)
Lower 25.400 – 25.450 (1.0000 – 1.0020) 25.460 (1.0023)
Caliper piston O.D.
(CBF600SA/NA)
Upper 22.585 – 22.618 (0.8892 – 0.8905) 22.560 (0.8882)
Middle 22.585 – 22.618 (0.8892 – 0.8905) 22.560 (0.8882)
Lower 22.585 – 22.618 (0.8892 – 0.8905) 22.560 (0.8882)
Caliper piston O.D.
(CBF600S/N)
Upper 25.318 – 25.368 (0.9968 – 0.9987) 25.310 (0.9965)
Lower 25.318 – 25.368 (0.9968 – 0.9987) 25.310 (0.9965)
Rear Specified brake fluid DOT 4 –
Brake pedal height 67.5 (2.66) –
Brake disk thickness 5.0 (0.20) 4.0 (0.16)
Brake disc runout. – 0.30 (0.012)
Master cylinder I.D.
(CBF600SA/NA)
15.870 – 15.913 (0.6248 – 0.6265) 15.925 (0.6270)
Master cylinder I.D. (CBF600S/N) 14.000 – 14.043 (0.5512 – 0.5529) 14.055 (0.5533)
Master piston O.D. (CBF600SA/NA) 15.827 – 15.854 (0.6231 – 0.6242) 15.815 (0.6226)
Master piston O.D. (CBF600S/N) 13.954 – 13.984 (0.5494 – 0.5510) 13.945 (0.5490)
Caliper cylinder I.D. 38.180 – 38.230 (1.5031– 1.5051 ) 38.240 (1.5055)
Caliper cylinder O.D. 38.098 – 38.148 (1.4999– 1.5019 ) 38.090 (1.4996)
ITEM SPECIFICATIONS
Battery Capacity 12V – 8.6 Ah
Current leakage 2.0 mA max.
Voltage
(20°C/68°F)
Fully charged 13.0 – 13.2 V
Needs
charging
Below 12.3 V
Charging current Normal 0.8 A/5 – 10 h
Quick 4.5 A/1.0 h
Alternator Capacity 0.333 kW/5,000 min
-1
(rpm)
Charging coil resistance (20°C/68°F) 0.1 – 1.0 Ω
ITEM SPECIFICATIONS
Spark plug NGK CR8EH-9
DENSO U24FER9
Spark plug gap 0.80 – 0.90 mm (0.031 – 0.035 in)
Ignition coil peak voltage 100 V minimum
Ignition pulse generator peak voltage 0.7 V minimum
Ignition timing ("F"mark) 4° BTDC at idle
Idle speed 1,300 ± 100 min
-1
(rpm)
