GENERAL INFORMATION
1-14
STANDARD TORQUE VALUES
ENGINE & FRAME TORQUE VALUES
• Torque specifications listed below are for important fasteners.
• Others should be tightened to standard torque values listed above.
ENGINE
MAINTENANCE
LUBRICATION SYSTEM
FUEL SYSTEM (PGM-FI)
COOLING SYSTEM
ENGINE REMOVAL/INSTALLATION
FASTENER TYPE
TORQUE
FASTENER TYPE
TORQUE
N·m (kgf·m, lbf·ft) N·m (kgf·m, lbf·ft)
5 mm hex bolt and nut 5.2 (0.5, 3.8) 5 mm screw 4.2 (0.4, 3.1)
6 mm hex bolt and nut 10 (1.0, 7) 6 mm screw 9.0 (0.9, 6.6)
8 mm hex bolt and nut 22 (2.2, 16) 6 mm flange bolt (8 mm head, small flange) 10 (1.0, 7)
10 mm hex bolt and nut 34 (3.5, 25) 6 mm flange bolt (8 mm head, large flange) 12 (1.2, 9)
12 mm hex bolt and nut 54 (5.5, 40) 6 mm flange bolt (10 mm head) and nut 12 (1.2, 9)
8 mm flange bolt and nut 27 (2.8, 20)
10 mm flange bolt and nut 39 (4.0, 29)
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Spark plug 4 10 16 (1.6, 12)
Timing hole cap 1 45 18 (1.8, 13) Apply grease to the threads.
Engine oil filter cartridge 1 20 26 (2.7, 19) Apply engine oil to the
threads and O-ring.
Oil filter boss 1 20 See page 3-14 Apply a locking agent to the
threads.
Engine oil drain bolt 1 12 30 (3.1, 22)
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Oil pump assembly bolt 3 6 12 (1.2, 9) CT bolt
Oil pump driven sprocket bolt 1 6 15 (1.5, 11) Apply a locking agent to the
threads.
Oil pipe A mounting bolt 2 6 12 (1.2, 9) Apply a locking agent to the
threads.
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
ECT sensor 1 12 23 (2.3, 17)
Insulator band screw (Throttle
body side)
4 5 See page 5-84
Insulator band screw (Cylinder
head side)
4 5 See page 5-75
Fuel rail mounting bolt 4 6 5.1 (0.5, 3.8)
IACV setting plate screw 2 4 2.1 (0.2, 1.5)
IACV joint screw 1 4 2.1 (0.2, 1.5)
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Water pump assembly bolt 2 6 12 (1.2, 9) CT bolt
Water pump impeller bolt 1 6 12 (1.2, 9)
Thermostat housing cover bolt 2 6 12 (1.2, 9) CT bolt
ITEM Q'TY
THREAD TORQUE
REMARKS
DIA. (mm) N·m (kgf·m, lbf·ft)
Drive sprocket bolt 1 10 54 (5.5, 40)
