ANTI–LOCK BRAKE SYSTEM (ABS; CBF600SA/NA)
16-2
ANTI–LOCK BRAKE SYSTEM (ABS ; CBF600SA/NA)
ABS SYSTEM LOCATION
ABS MODULATOR
REAR BRAKE CALIPER
SERVICE CHECK CONNECTOR
FRONT WHEEL SPEED SENSOR
2P (BLUE) CONNECTOR
ABS FUSE BOX
(ABS MAIN FUSE)
REAR WHEEL SPEED SENSOR 2P (RED) CONNECTOR
FRONT PULSER RING
FRONT WHEEL SPEED SENSOR
FRONT BRAKE CALIPER
REAR PULSER RING
REAR WHEEL
SPEED SENSOR
