MAINTENANCE
3-7
AIR CLEANER
Remove the left side cover (page 2-5).
Remove the air cleaner duct mounting screws.
Remove and inspect the air cleaner element in
accordance with the maintenance schedule (page 3-
4).
Clean the air cleaner element with compressed air
from outside of the element.
Install the removed parts in the reverse order of
removal.
CRANKCASE BREATHER
• Service more frequently when ridden in rain, at
full throttle, or after the motorcycle is washed or
overturned. Service if the deposit level can be
seen in the drain hose.
Remove the left side cover (page 2-5).
Remove the crankcase breather drain hose and
drain the deposits into a suitable container, then
reinstall the drain hose with the hose clamp.
Install the air
cleaner element
with its opening
facing out.
